Innovative three-layer panel with composite reinforcement
We manufacture high quality products in accordance with the Russian standard GOST 31938-2012 and the interstate standard GOST 31310-2015
Advantages
of panels with composite reinforcement
* the calculation was made for a building with a perimeter of 100 m
Savings on insulation
Thanks to the absence of thermal bridges when using composites, it is possible to reduce the thickness of the insulation from 170mm to 130mm
up to
25%
Reduced concrete consumption
By reducing the thickness of the exterior facade layer by 50%
25%
up to
Reducing the weight of the entire panel
By reducing the thickness of the exterior facade layer by 50%
25%
up to
Additional usable area
By reducing the thickness of the exterior facade layer by 50%
30
m2*
Reducing panel thickness
Using SIREP composite mesh in the exterior facade layer of the panel will reduce its thickness from 80mm to 40mm
25%
up to
Composite products used in a three-layer panel
Designed to connect all layers of panels together. Used to replace similar steel products
Designed to replace traditional galvanized or stainless steel mesh
Designed for loading/unloading operations and installation, and used in the process of extracting concrete products from the formwork
What properties does composite reinforcement have?
No fear of chemical impact and moisture, which affects the durability of the use of materials, and the possibility of their use at any time of the year
Corrosion and chemical resistance
The tensile strength of composite bars and grid is 3 times higher than that of a steel ones
Tensile strength
Does not conduct electricity and does not interfere with the spread of the signal of mobile phones and the Internet
Dielectric, no radio interference
Does not form "thermal bridges", which improves the thermal insulation parameters of the construction site
Low thermal conductivity
Even in severe frosts, composite reinforcement does not lose its properties. The temperature threshold for use ranges from -70°С to +100°С
Heat resistance
The lack of need for welding simplifies the installation - any worker can handle reinforcement wire-tying, with a minimum set of tools
Easy to install
What difficulties thermal bridges can cause:
Solves the problem of thermal bridges
Thermal bridges are local sections of the building through which increased heat transfer passes. Usually, thermal bridges are steel parts in brick or block masonry, window and door lintels, etc.
Condensate leads to the appearance of mold in apartments, which harms the health of residents, and worsens the appearance of the home
Сondensate formation
Increased energy consumption
The expensive heat escapes through the thermal bridges, so the heating costs of the building increase by about 30%
Reduced security
Thermal bridges lead to cracks, a decrease in the bearing capacity of the structure, which leads to an increase in the cost of building maintenance
Get product samples
We're confident in the quality of our products, because we comply with all legal requirements for composite building materials. You can also make sure by ordering samples with delivery
